Designed for versatility and adaptability, the Shelf Rack Roll Forming Machine is engineered to meet the diverse needs of modern storage system manufacturers, capable of producing not only standard shelf rack uprights but also custom profiles tailored to specific project requirements. Its flexible design allows for easy adjustment of forming parameters, making it suitable for a wide range of profile sizes and geometries, from simple C-shaped uprights to complex multi-bend profiles used in heavy-duty storage systems. The machine’s PLC control system can store up to 50+ production recipes, enabling quick switching between different profile designs with minimal downtime, a key advantage for manufacturers serving diverse customer bases and handling custom orders.
The machine’s material handling capabilities are equally impressive, supporting cold-rolled steel, hot-dip galvanized steel, and pre-painted steel, with material thicknesses ranging from 1.0 mm to 3.5 mm and widths from 50 mm to 250 mm. This versatility ensures that manufacturers can produce shelf uprights suitable for various environments, including humid warehouses, cold storage facilities, and retail spaces, where corrosion resistance and durability are critical. The forming stations, numbering 12 to 20, are equipped with interchangeable tooling, allowing for easy customization without the need for expensive equipment modifications. The servo-driven feeding and forming system ensures consistent material flow and precise bending, resulting in profiles with uniform dimensions and smooth surfaces.
|
Parameter
|
Specification
|
|
Machine Type
|
Shelf Rack Roll Forming Machine
|
|
Material Thickness
|
1.0 ~ 3.5 mm
|
|
Material Width
|
50 ~ 250 mm
|
|
Forming Stations
|
12 ~ 20 stations
|
|
Max Forming Speed
|
10 ~ 18 m/min
|
|
Decoiler
|
Manual / Hydraulic / Motorized
|
|
Cutting Method
|
Flying Cut / Hydraulic Shear
|
|
Drive System
|
Electric / PLC Control
|
|
Power
|
20 ~ 35 kW
|
|
Machine Dimensions (L×W×H)
|
10–14 m × 1.5 m × 1.8 m
|
|
Machine Weight
|
7 ~ 14 tons
|
|
Tolerance
|
±1 mm
|
|
Suitable Material
|
Cold Rolled Steel / Galvanized Steel
|
|
Optional Features
|
Automatic Punching,Stacking,Labeling
|
To ensure long-term reliability, the machine features a heavy-duty frame constructed from high-strength steel, with all critical components made from wear-resistant materials and treated with heat treatment. The power requirement ranges from 20 kW to 35 kW, balancing high performance with energy efficiency, making it suitable for continuous operation without excessive power consumption. The cutting system, available in flying cut or hydraulic shear options, delivers clean, accurate cuts with a tolerance of ±1 mm, ensuring that each upright is ready for assembly without additional processing. Optional features such as automatic lubrication, error alarm systems, and remote monitoring further enhance the machine’s usability and reliability, making it a flexible, cost-effective solution for manufacturers of all sizes.
