Product Overview
The Frame Bracing Roll Forming Machine is a high-performance automated production system specifically engineered for manufacturing precision frame bracing components, including upright rack columns, shelf upright posts, and pallet rack uprights. As a core equipment for warehouse shelving and storage rack systems, it integrates advanced forming, cutting, and intelligent control technologies, enabling stable and efficient mass production. With strong customization capabilities to adapt to diverse profile requirements, this machine has become a trusted choice for global storage rack manufacturers due to its reliable performance and flexible configuration.
Core Technical Specifications
-
Raw material: Cold-rolled steel, Galvanized steel (optional stainless / color-coated steel), covering mainstream and customized material needs
-
Material thickness: 1.5 – 3.0 mm, suitable for high-strength frame bracing production
-
Roller material: GCr15 (or optional Cr12) alloy steel, heat treated (quenched / hardened), featuring excellent wear resistance and deformation resistance
-
Roller hardness: HRC 58 – 62° (depending on heat treatment), ensuring long-term stable forming precision
-
Number of forming stations: 16 – 28 stations (profile dependent), adaptable to different profile structures for uniform stress distribution
-
Forming (line) speed: 5 – 15 m/min (depending on profile & configuration), balancing production efficiency and product quality
-
Main motor power: 15 – 22 kW (depending on model), providing sufficient and stable power support
-
Cutting / Shearing system: Hydraulic cutting (or saw-cut); cutting blades made of heat-treated Cr12 / Cr12MoV, ensuring smooth cutting surfaces and high precision
-
Control system: PLC control (Siemens / Panasonic / Delta optional) — supports automatic forming, punching, cutting, length & quantity control, realizing full-process intelligent operation
-
Decoiler: manual or hydraulic decoiler (capacity configurable, e.g. 3t–5t), matching different production scale requirements
-
Material width: As per customer’s profile drawing / specification, fully customized to meet unique profile designs
-
Profile types: Upright rack columns / shelf upright posts / pallet rack uprights / warehouse shelving uprights, covering core frame bracing applications
-
Power supply / Voltage: 380 V, 50 Hz, three-phase (customizable per customer requirement), adaptable to global power standards
Global One-Stop Service
Pre-sales Consulting
We provide multilingual technical support (English, German, Russian, Spanish, Arabic), on-site factory layout planning, and customized production solutions based on customers' specific profile drawings, material requirements, and production scales.
Sales Support
Professional packaging is adopted to prevent equipment damage during transportation. We provide complete industrial equipment customs clearance documents and arrange professional engineers for on-site installation, commissioning, and debugging. Systematic training on equipment operation, maintenance, and quality control is provided for customer teams to ensure proficient use.
After-sales Service
24/7 online technical assistance is available to solve customers' problems in a timely manner. On-site maintenance support is provided within 48 hours in key regions. We offer a long-term warranty for core components, lifelong maintenance guidance, and free software upgrade services to ensure the continuous and stable operation of the equipment.
Certifications
CE | ISO9001:2015 | SGS | TUV Rheinland
Typical Applications
-
Production of upright rack columns for heavy-duty storage racks
-
Manufacturing of shelf upright posts for commercial and industrial warehouses
-
Customized production of pallet rack uprights for logistics distribution centers
-
Production of warehouse shelving uprights for cold-chain storage and chemical storage facilities
